ARMORING MODIFICATION
All four sides of the passenger compartment and the roof of the
vehicle are protected using high-quality armor steel and glass defeating
7.62x51mm M80 Nato Ball ammunition (U.S. NIJ level III, CEN level FB6/BR6) and
5.56x45 SS109 ammunition (CEN level FB5/BR5 and FB6/BR6) at 0° incidence (90°
to the surface) and 10m range according to CEN1063 and CEN1522.
WINSHIELD
OEM Windshield is removed and replaced with NIJ/CEN/STANAG tested
Multi-layered ballistic glass. It’s thickness range between 39mm to 80mm. All
transparent areas are multi-layer and polycarbonate coated to protect against
the following and all lesser weapons/ammunitions at 90° impact angle in
accordance with the above specifications.
Ø Calibre 7.62 x 39 mm, FJ/PB/FeC, AK 47 Kalashnikov
Ø Calibre 5.56 x 45 mm, FJ/PB/SCP, M16 Colt
Ø Calibre 7.62 x 51 mm, FJ/PB/SC, (FN "FAL"" /
"LAR" NATO rifle
FLOOR
Floor of the vehicle is fitted with a blast protection to protect
occupants against fragmentation from simultaneous detonation of 2 DM-51 German
ordnance hand grenades or equivalent.
SUSPENSION AND BRAKING SYSTEM
Suspension and braking systems of the vehicle are assessed and are
modified to support the added weight caused by the armor. Other armoring
options for the vehicle are also installed at this time
OTHER MODIFICATION
Ø Hinge mounting points are reinforced both in the pillars and in
the doors in a way that the armouring of the door is supported by the armouring
of the pillar.
Ø Heavy-duty hinges with in-built door-stop.
Ø Fuel-tank(s) protected with steel armour-plates.
Ø The battery and control module of the engine are protected to the
same level as the opaque areas.
Ø Front fenders armored to protect against side impact bullets
Ø Armor overlap at all doors to prevent penetration through door
posts and pillars.
Ø Armored louvered Radiator protection concealed behind hood of
vehicle
Ø Powered glass operations 4-6 inches if required
Ø Customized tailpipe protection
